产品型号：SD02M50DL产品描述：智能功率模块(IPM)，500V/2A3相全桥驱动应用：空调室内/外机冰箱压缩机油烟机风扇空气净化器洗碗机水泵产品概述：SD02M50DL/DLS是高度集成、高可靠性的3相无刷直流电机驱动电路，主要应用于较低功率电机驱动，如风扇电机。其内置了6个快恢复MOSFET和3个半桥HVIC栅极驱动电路。SD02M50DL/DLS内部集成了欠压保护电路，提供了优异的保护和故障安全操作。由于每一相都有一个独立的负直流端，其电流可以分别单独检测。



Product Type: SD02M50DL Product Description: Intelligent Power Module (IPM), 500V/2A3 Phase Full Bridge Driving Applications: Air Conditioning Indoor/External Refrigerator Compressor Fume Machine Fan Air Purifier Dishwasher Water Pump Products Overview: SD02M50DL/DLS is a highly integrated and reliable 3-phase Brushless DC Motor Driving Circuit, mainly used for lower power. Rate motor drive, such as fan motor. It has built 6 fast recovery MOSFET and 3 half bridge HVIC gate drive circuits. The SD02M50DL/DLS incorporates an undervoltage protection circuit, providing excellent protection and fail safe operation. Because each phase has an independent negative DC terminal, its current can be detected separately.



SD05M50DL/DLS采用了高绝缘、易导热，低EMI的设计，提供了非常紧凑的封装体，使用非常方便，尤其适合要求紧凑安装的应用场合。主要特点：内置6个500V/2A的快恢复功率MOS管内置高压栅极驱动电路(HVIC)内置欠压保护完全兼容3.3V和5V的MCU的接口，高电平有效3个独立的负直流端用于变频器电流检测的应用优化并采用了低电磁干扰设计绝缘级别：1500Vrms/min产品名称封装形式打印名称材料包装SD02M50DLDIP-23HSD02M50DL无铅料管SD02M50DLSSOP-23HSD02M50DLS无铅料管



SD05M50DL/DLS is designed with high insulation, easy thermal conductivity and low EMI. It provides a very compact package and is very convenient to use, especially for applications requiring compact installation. Main features: Built-in 6 500V/2A fast recovery power MOS tube built-in high voltage gate drive circuit (HVIC) built-in undervoltage protection fully compatible with 3.3V and 5V MCU interface, high-level effective three independent negative DC terminals for current detection of frequency converter application optimization and low electromagnetic interference design insulation level: 1500Vrms/min product Name Packaging Form Print Name Material Packaging SD02M50DLDIP-23HSD02M50DL Lead-free Pipe SD02M50DLSSOP-23HSD02M50DLS Lead-free Pipe
